Original Genius Kilo Amigo Ja332 868 Mhz Gate Opener Remote Control

GENIUS

KILO TX2 868MHZ

ROLLING CODE

2-channel

ORIGINAL

Procedure for duplication:

1. Press the first 2 keys of the simultaneously
MASTER radio control already working in the receiver**
and keep them pressed until the LED flashes. Release both buttons.

2. While the LED is flashing, move the vehicle towards the front
MASTER radio control already working in the receiver to the NEW radio control (to be coded).

3. On the MASTER radio control (already working in the receiver),
while the LED is still flashing, press and hold
pressed the first key you want to duplicate. Its LED will light up steadily.

4. Press the button on the new remote control (to be coded).
equivalent to be copied and released only when its LED has not flashed twice.

5. Release the MASTER radio control button (already working in the receiver).

6. Repeat the procedure for all the keys you want to duplicate.

If the procedure should not be successful or if errors should be made during the
programming wait 20 seconds and start again from point 1.
*To recognize a Master remote control, press any key on the remote control already
working in the receiver and check what type of flashing its LED emits:
- if it emits a short flash before turning on with a fixed light it is a MASTER and can
be duplicated by following the procedure described on this page.
- if it turns on immediately with a steady light it is a SLAVE remote control and cannot
be duplicated. In this case you will have to contact exclusively the installer who has you
the automation is mounted.
**Be careful not to confuse the two remote controls: the MASTER remote control is already functioning
receiver with the new one to be coded
