Pair of Universal Spare Photocells 12/24v Compatible With Vds 12/eco

Save €0,63

Model: eb-234410824499
Warranty: 24 months
Supplier: DIEFFEMATIC
Price:
€12,00 €12,63
COUPON 'BLACK10' -10%

Do you need help with this product? Contact us
Whatsapp-Share

Share this product
Email-Share Whatsapp-Share Facebook-Share Copy-Share

Shipping

shipping in 2-4 business days

Description

Pair of Photocells

from WALL



12/24v

with solar filter

Universal

Professional

Mod. 12/ECO


Outdoor photocell, refined and coordinated design, in infrared filter-transparent material.

The photocell creates a single infrared beam barrier with digital coding diversified on two possible channels (Channel A or Channel B).

Interruption of the infrared beam activates a double relay device which switches a contact from C/NC to C/NO or vice versa.

The photocell can be used indifferently as an accessory device for gate automation systems

or sliding doors or as an anti-theft sensor to intercept the presence of unauthorized people and generate the relevant alarm.

Robust: polycarbonate shell

MAX RANGE 12 METERS

DIMENSION 100 x 44 x 35 MM



CHARACTERISTICS:

Power supply 12-24 Vdc / Vac

Dim. (mm) 100 x 44 x 35

Metallic Taunt

Crystal lens, 12 m range

Synchronized, 12 m range

Coded two-channel digital operation

Double safety relay

TX/RX alignment LEDs

Nominal supply voltage 12.5Vdc ±5% / 24V~ ±5%

Absorption: RX (12V,5cc) 30mA

Absorption: TX (12.5Vcc) 35Ma

Absorption: RX (24Vca) 70mA

Absorption: TX (24Vca) 80mA

Emission band 950nm

Protection degree of the container IP44



Operating temperature -20°C ÷ +55°C

24 month warranty
