Description
Opera oleodynamic operator for swinging doors up to 4 m and 500 kg of weight. Useful race 270 mm maneuver 33 sec and maximum opening corner of 123 °. Lock system: electroserature
SKU: P935012 00001
U-Link: No
Control unit: Alcor n. Rigel5
Absorbed power: 250 W
Finecors type: working time
Slowdown: no
Reaction to the impact: hydraulic clutch
Block: Electroserration
Unlock: Reversible
Usage frequency: very intensive
Environmental conditions (min): -10 ° C
Environmental conditions (max): 60 ° C
Degree of protection: IP57
Weight of the actuator: 8.7 kg
Tension: 230 V
Anta weight: 500 kg
Kit: -
Environment of use: residential industrial collective tertiary
Complete system: x
Useful running stem: 270 mm
Maximum corner: 123 °
Maneuver time: 33 sec
Anta length: 4 m
Motor power supply: 230 V
Mod. Lux L
Recommended accessories:
D113706 00002 alcor n
D111013 me
D113680 00002 Alpha SD
D113693 00003 Rigel 5
D113748 00002 RADIUS B LTA 230 R1
D113749 00002 Radius B LTA 230 R2
D121016 ECB DX
D121017 ECB SX
D121018 Vertical ECB
D831081 CMS
P121023 Q.bo Key WM AV
P121022 Q.bo Key WM
P123001 00001 EBP
P123006 00001 EBPE 52
P123008 00001 EBPE 75
P123001 00013 EBP 24
N190104 BIR C
P111401 00001 Ventimiglia NS
N733426 Arb Lux
N733474 Arb Lux G
D730178 PLE
N99131 NAT
P123025 B 00 R02
D111904 Mitto B RCB02 R1
P121024 Q.BO Touch
P11526 Desme A15
P903018 PHP
24 months warranty
