BFT
KUSTOS BT KIT A25
Product code R935307 00004
Complete 24V kit for swing gates up to 400kg in weight and 2.5m in length.
| Control center | THALIA |
| Power supply card | 230 V |
| Motor voltage | 24V |
| Power absorbed | 40W |
| Max. door width | 2.5 m |
| Max. weight of the swing | 400 kg |
| Useful stem stroke | 295mm |
| Maximum angle | 118 ° |
| Maneuver time | 13 s |
| Limit switch type | Magnetic |
| Slowing down | Yes |
| Block | Mechanical |
| Unlock | Custom key |
| Reaction to impact | D-Track, U-Link |
| Frequency of use | intensive |
| Degree of protection | IP44 |
| Environmental conditions | -20 ÷ 55 °C |
| U-Link | No |
The KIT includes
2 - KUSTOS BT A25 Electromechanical irreversible operator
1 - MITTO B RCB04 R1 12V four-channel transmitter 433MHz rolling code
1 - THALIA Control panel for 1 or 2 24V operators for swing gates
1 - Q.BO KEY WM External key selector with double contact.
1 - DESME A15 Pair of self-aligning photocells. Range 30 m. Power supply 24 V ac/dc.
1 - RADIUS B LTA 24 R1 Flashing light with integrated antenna for 24V powered motors
24 month warranty
eb: 233249128675
INTERNATIONAL CODE BFT 2611939
