Description

Chain actuator

Mod. KIMO202 24V 200N

SKU: 6050551

Maximum stroke 210 mm
Black colour

Recessed electric chain actuator for top-hung, bottom-hung and pivot windows. KIMO 202 is NEKOS's response to the request for concealed installations inside windows and doors with increasingly smaller profiles.
Compact (21x28.5x354 mm), sturdy (structure in high-strength composite material) and in 3 color variants (white, black and grey), the new Kimo202 lends itself to being an extremely versatile solution that can be installed both recessed and surface-mounted. view.
Extremely silent (40 dB(A)), it is equipped with a patented 3-link chain and features three opening strokes with quick selection via dip-switch.
The standard Syncro³ technology (NEKOS patent) allows the actuator to operate both alone and in systems of up to 8 units without the aid of control units.
The combination with the K-LOCK electromechanical lock also constitutes a burglar-proof window lock.
KIMO 202 can also be connected to AUX, the completion accessory for natural ventilation systems that use 24V DC motors.

Electric chain actuator, in high resistance composite material with glass fibre. Suitable for moving top-hung, bottom-hung and pivoted windows.
• Low voltage power supply of 24V (DC);
• NEKOS patented chain;
• Traction force of 200 N, thrust 150 N (100 mm);
• Three opening strokes selectable with dip-switch: 100, 170 and 250 mm;
• Progressive starting ramp;
• Power control over the entire stroke;
• Closing limit switch with power absorption and overload protection;
• Relax function, with relaxation of the mechanical parts after each stop due to power absorption;
• Supplied complete with tilting support brackets for recessed mounting and door attachment bracket. Retractable sash brackets with the possibility of inspecting the motor even with the window closed or in the absence of power.

Compliant with the relevant EU Directives (EMC Directives, Low Voltage Directives) and UL/CSA certified.

Applications:
Pivot Window
Attic window
Vasistas window
Protruding window

24 months warranty
