Description
Outdoor Brick-Shaped Magnetic Contact, 1 Piece, for Door and Window Alarms, NC Reed Contact, Vacuum-Sealed, Magnetic Sensitivity 13 mm, Max Voltage 30 V, Resistive Load 1 A, IP65, 4 Wires, 2 NC and 2 Tamper
Mod. ST-400CMMBFTD
SKU: ST-400CMMBFTD
ST-400 Outdoor NC magnetic contact in brick-shaped ABS housing. Maximum switching current 1 A at 30 V resistive load. Magnetic range 13 mm. Comprises 2 parts of the same shape. The part with the wires contains a vacuum-sealed glass reed switch, in the NO position. Bringing the magnet close causes the contacts to close into the NC position. The 2 remaining wires are NC for connecting the tamper. The other part contains a permanent magnet. Surface-mounted outdoor installation. Particularly suitable for protecting frames of any kind, provided they are non-ferrous, doors, windows, piece counters, limit switches for moving machinery, and more. Install the contact part, i.e. the part with the wires, on the fixed part of the frame, while the magnet is positioned opposite it on the moving part (door). The protected frames must be completely closed. Complies with CEI 79/2 Level 1. Protection rating IP 65. Operating temperature from - 25 to +70° C. Installed dimensions L32XH25XS8 mm. Weight 11 g. Assembled and selected at the Securvera plant in Rome. Guaranteed in accordance with the law for 24 months against manufacturing defects and faults. Complies with European directives: EN50131-2-6. EEC 89/336 + 92/31 +93/68 D.L 04/12/1992 N 476. ERP 2009/125/CE; "RoHS" 2015/863/UE; R&TTE 99/05/EC. Electromagnetic Compatibility 2014/30/UE; Low Voltage 2014/35/UE and subsequent amendments, continuously updated
LIST OF COMPONENTS FOR SALE:
01 ST-400 Brick-Shaped ABS Magnetic Contact RED Vacuum-Sealed Max Current 30 V 1 A IP 65 Protection 4 Wires 2 NC, 2 Tamper
01 SV-GAR Warranty Certificate as Required by Law: 24 Months; Qualified Installation Requirements D.M.37/2008, Lifetime Coverage Against Manufacturing Defects
01 SV-IST Detailed Installation Instructions; The Following Must Be Observed: Connections, Polarity, Supply Voltage, Load
CLICK HERE TO DOWNLOAD THE MANUAL OR DIY GUIDE:
MANUFACTURER'S MANUAL
