Description
Outdoor Magnetic Sensor, 1 Piece, for Burglar Alarm on Windows and Frames, NC Vacuum-Sealed Reed Contact, Magnetic Sensitivity 13 mm, Max Voltage 30 V, Resistive Load 1 A Max, IP65, 4 Wires, 2 NC and 2 Tamper
Mod. ST-400CMMBFTB
SKU: ST-400CMMBFTB
ST-400 outdoor NC magnetic contact in brick-shaped ABS housing. Maximum switching current 1 A at 30 V resistive load. Magnetic gap: 13 mm. Consists of 2 pieces of the same shape. The wired part contains a vacuum-sealed glass reed switch, normally open. When the magnet approaches, the contacts close to the NC position. The 2 remaining wires are NC for tamper connection. The other part contains a permanent magnet. For exposed outdoor installation. Particularly suitable for protecting frames in general, provided they are non-ferrous, doors, windows, piece counters, limit switches for moving machinery, and more. Install the contact part, i.e. the wired part, on the fixed part of the frame, and the magnet opposite it on the moving part (door). The protected frames must be fully closed. Complies with CEI 79/2 Level 1. IP 65 protection rating. Operating temperature from - 25 to +70° C. Installed dimensions L32XH25XS8 mm. Weight 11 g. Product assembled and selected at the Securvera facility in Rome. Guaranteed by law for 24 months against manufacturing defects and faults. Complies with European directives: EN50131-2-6. CEE 89/336 + 92/31 +93/68 D.L 04/12/1992 N 476. ERP 2009/125/CE; "RoHS" 2015/863/UE; R&TTE 99/05/EC. Electromagnetic Compatibility 2014/30/UE; Low Voltage 2014/35/UE and subsequent amendments, continuously updated
LIST OF COMPONENTS FOR SALE:
01 ST-400 Brick-Shaped ABS Magnetic Contact, RED Vacuum-Sealed, Max Current 30 V 1 A, IP 65 Protection, 4 Wires, 2 NC, 2 Tamper
01 SV-GAR Warranty Certificate as Required by Law: 24 Months; Qualified Installation Requirements D.M.37/2008, Lifetime Coverage Against Manufacturing Defects
01 SV-IST Detailed Installation Instructions; The Following Must Be Observed: Connections, Polarity, Supply Voltage, Load
CLICK HERE TO DOWNLOAD THE MANUAL OR DIY GUIDE:
MANUFACTURER'S MANUAL
24-month warranty
