Shipping
shipping in 2-4 business days
Description
AUTOMATIC BARRIER KIT
for rods up to 5 m WITH SOLAR PANEL
opening time 7 sec.
Professional
THE KIT INCLUDES:
24V AUTOMATIC BARRIER, CONTROL CENTRAL, STRIKING PLATE
5 MT ROD
1 CHANNEL RADIO RECEIVER
4 CHANNEL REMOTE CONTROL
SOLAR PANEL KIT
PAIR OF PHOTOCELLS
MOBILE ROD SUPPORT
REFLECTIVE STICKERS FOR POLES
WARNING SIGN
Characteristics:
- Irreversible;
- Self-supporting powder-coated steel cabinet;
- Die-cast aluminum engine box;
- Cast iron and steel gears;
- High performance electric motor;
- Mechanical parts lubricated with lithium grease against corrosion, oxidation and rust, promoting maximum life of the levers;
- Mechanical and electronic limit switch in opening and closing;
- Long-lasting compression spring balance;
- Easy programming software;
- Control equipment with radio receiver and antenna;
- Anti-crushing device with reverse gear (EN 12453);
- Electronic torque regulation;
- Speed decelerations (EN 12453)
- Emergency release with easy crank operation;
- Anti-blackout battery kit (OPTIONAL);
- Solar panel power supply KIT consisting of: 5W photovoltaic panel Support and fixing bracket for panels Watertight box with control unit mod. SP01 - 2 12V 7Ah batteries - accessories box. Maximum number of non-consecutive openings 20.
- Line power supply 230 V - transformer including 24 V;
The Electromechanical Barrier with a rod of up to 6 meters is the best solution for garage parking and private car parks.
To meet these needs we have carefully created an elegant design, we have managed to ensure easy installation.
For the construction we used high-tech materials and manufacturing processes.
The control board, positioned in the upper part of the barrier, is easily accessible to the installer.
It is equipped with slow stops both on opening and closing, the spring adjustment is very simple.
Personalized key unlocking.
CLICK ON THE LINKS FOR THE INSTRUCTION MANUALS:
MECHANICAL INSTALLATION MANUAL
SUNPOWER KIT MANUAL
Technical data:
Power supply: 24v
Operating temperature: -30+70 °C
Rod length: max 6m
Power absorbed: 60W
Motor absorption: 3 A
Degree of protection: IP54
Lubrication: permanent grease
Weight: 34kg
24 month warranty
