Description
Outdoor Magnetic Sensor, 5 Pieces, for Window Burglar Alarm, Vacuum-Sealed NC Reed Contact, Magnetic Sensitivity 13 mm, Max. Voltage 100 V, 1 Ah Resistive Load, IP65 Protection, 4 Wires: 2 NC and 2 Tamper
Mod. ST-400CSMBFTB
SKU: ST-400CSMBFTB
ST-400 Outdoor NC magnetic contact in brick-shaped ABS housing. Maximum current 1 A at 30 V resistive load. Magnetic range 13 mm. Consists of 2 parts of the same shape. The part with the wires contains a vacuum-sealed reed switch in a glass capsule, in the NO position. Bringing the magnet close causes the contacts to close into the NC position. The 2 remaining wires are NC for connecting the tamper. The other part contains a permanent magnet. Surface-mounted outdoor installation. Particularly suitable for protecting frames in general, provided they are non-ferrous, doors, windows, piece counters, limit switches for moving machinery, and more. The contact part, i.e. the one with the wires, must be installed on the fixed part of the frame, while the magnet must be positioned opposite it on the moving part (door). The protected frames must be completely closed. Compliant with CEI 79/2 Level 1. IP 65 protection rating. Operating temperature from - 25 to +70° C. Installed dimensions L32XH25XS8 mm. Weight 11 g. Product assembled and selected at the Securvera facility in Rome. Guaranteed for 24 months by law against manufacturing defects and faults. Complies with European directives: EN50131-2-6. EEC 89/336 + 92/31 +93/68 D.L 04/12/1992 N 476. ERP 2009/125/CE; "RoHS" 2015/863/UE; R&TTE 99/05/EC. Electromagnetic Compatibility 2014/30/UE; Low Voltage 2014/35/UE and subsequent amendments, continuously updated
LIST OF COMPONENTS FOR SALE:
05 ST-400 Vacuum-Sealed Reed Magnetic Contact in Brick Shape, Red ABS, Max. Current 30 V 1 A, IP 65 Protection, 4 Wires: 2 NC, 2 Tamper
01 SV-GAR Warranty Certificate as Required by Law: 24 Months; Qualified Installation Requirements under Ministerial Decree 37/2008, Lifetime Coverage Against Manufacturing Defects
01 SV-IST Detailed Installation Instructions; The Following Must Be Observed: Connections, Polarity, Supply Voltage, Load
CLICK HERE TO DOWNLOAD THE MANUAL OR DIY GUIDE:
MANUFACTURER'S MANUAL
24-month warranty
