Description
Recessed Magnetic Contact 3 Magnetic Sensors 8 mm Reed NC Output 4-Wire Connection Max Switching Voltage 100 V 10 W Resistive Load Anti-Theft for Non-Ferrous Window Frames Cylindrical ABS Shape IP65 Protection
Mod. ST-415CPTSMPE
SKU: ST-415CPTSMPE
ST-415 Cylindrical Nail-Type Recessed ABS Magnetic Contact. Vacuum-sealed glass capsule contacts, NC and NC tamper. 4-wire connection, over 10 Cm long. Magnetic field sensitivity 8 mm. Consists of 2 pieces of the same shape. Secured by force-fitting into a suitable hole. The wire section contains the reed contact; bringing the magnet close causes the contact to close. The other section contains a permanent magnet. Suitable for monitoring the opening of doors and non-ferrous window frames, concealed installation. Complies with CEI 79-2 Level 1. General features and specifications: Operating temperature from -25 to +70°. IP 65 protection. Max voltage 100 Vcc. Maximum power 10 W. Installed dimensions L58XD8XT10 mm. Weight 9 gr. Product assembled and selected at the Securvera factory in Rome. Guaranteed for 24 months by law against manufacturing defects and faults. Complies with European directives: EN50131-2-6 CEE 89/336 + 92/31 +93/68 D.L 04/12/1992 N 476. ERP 2009/125/CE; "RoHS" 2015/863/UE; R&TTE 99/05/EC. Electromagnetic Compatibility 2014/30/UE; Low Voltage 2014/35/UE and subsequent amendments, continuously updated
COMPONENTS FOR SALE:
03 ST-415 ABS Recessed Nail-Type Magnetic Contact RED Vacuum-Sealed Max Current 100 V 10 W IP41 Protection NC Contact. 2 Terminals
01 SV-GAR Legally Required Warranty Certificate: 24 Months; Qualified Installation Requirements D.M.37/2008, Lifetime Coverage Against Manufacturing Defects
01 SV-IST Detailed Installation Instructions; Must Be Followed: Connections, Polarity, Supply Voltage, Load
CLICK HERE TO DOWNLOAD THE MANUAL OR DIY GUIDE:
MANUFACTURER'S MANUAL
24-month warranty
