Description
Recessed Cylindrical Magnetic Contact, Three 8 mm Magnetic Sensors, Reed, NC Output, 4-Wire Connection, Max Switching Voltage 100 V, 10W Resistive Load, Anti-Theft Protection for Non-Ferrous Window Frames, IP65 Protection
Mod. ST-415CPTSMPC
SKU: ST-415CPTSMPC
ST-415 Cylindrical magnetic contact, nail-shaped, recessed ABS. Vacuum-sealed glass capsule contacts, NC and NC tamper. 4-wire connection, over 10 cm long. Magnetic field sensitivity: 8 mm. Consists of 2 pieces with the same shape. Installed by force-fitting into a suitable hole. The part with the wires contains the reed contact; bringing the magnet close causes the contact to close. The other part contains a permanent magnet. Suitable for monitoring the opening of doors and non-ferrous window frames, concealed installation. Complies with CEI 79-2, 1st level. General features and specifications: Operating temperature from -25 to +70°. IP 65 protection. Max voltage 100 V DC. Maximum power 10 W. Installed dimensions L58XD8XT10 mm. Weight 9 g. Product assembled and inspected at the Securvera plant in Rome. Guaranteed for 24 months against manufacturing defects and faults, as required by law. Complies with the European directives: EN50131-2-6 CEE 89/336 + 92/31 +93/68 D.L 04/12/1992 N 476. ERP 2009/125/CE; "RoHS" 2015/863/UE; R&TTE 99/05/EC. Electromagnetic Compatibility 2014/30/UE; Low Voltage 2014/35/UE and subsequent amendments, continuously updated
LIST OF COMPONENTS FOR SALE:
03 ST-415 Recessed ABS Nail-Type RED Magnetic Contact, Vacuum-Sealed, Max Current 100 V 10 W, IP41 Protection, NC Contact, 2 Terminals
01 SV-GAR Warranty Certificate as required by law: 24 months; Qualified Installation Requirements D.M.37/2008, lifetime coverage against manufacturing defects
01 SV-IST Detailed Assembly Instructions; Must Be Followed: Connections, Polarity, Supply Voltage, Load
CLICK HERE TO DOWNLOAD THE MANUAL OR DIY GUIDE:
MANUFACTURER'S MANUAL
24-month warranty
