Description
Recessed Magnetic Contact, 2 Magnetic Sensors, 8 mm, Reed Switch, NC Output, 4-Wire Connection, Max. Switching Voltage 100 V, 10 W Resistive Load, Burglar Alarm for Non-Ferrous Window Frames, Cylindrical ABS, IP65 Protection
Model ST-415CPDSMPA
SKU: ST-415CPDSMPA
ST-415 Cylindrical nail-type recessed ABS magnetic contact. Vacuum-sealed glass reed contacts, NC and NC tamper. 4-wire connection, over 10 cm long. Sensitivity: magnetic field 8 mm. Comprises 2 pieces of the same shape. Secured by press-fitting into a suitable hole. The part with the wires contains the reed contact; bringing the magnet close causes the contact to close. The other part contains a permanent magnet. Suitable for monitoring the opening of doors and non-ferrous window frames, concealed installation. Complies with CEI 79-2, 1st level. General features and specifications: Operating temperature from -25 to +70°. IP 65 protection. Max. voltage 100 V DC. Maximum power 10 W. Installed dimensions L58XD8XT10 mm. Weight 9 g. Product assembled and selected at the Securvera facility in Rome. Statutory 24-month warranty against manufacturing defects and faults. Complies with European directives: EN50131-2-6 CEE 89/336 + 92/31 +93/68 D.L 04/12/1992 N 476. ERP 2009/125/CE; "RoHS" 2015/863/UE; R&TTE 99/05/EC. Electromagnetic Compatibility 2014/30/UE; Low Voltage 2014/35/UE and subsequent amendments, continuously updated
LIST OF COMPONENTS FOR SALE:
02 ST-415 ABS Recessed Nail-Type Magnetic Contact, Sealed Reed Switch, Max. Current 100 V 10 W, IP41 Protection, NC Contact, 2 Terminals
01 SV-GAR Statutory Warranty Certificate: 24 Months; Qualified Installation Requirements, Ministerial Decree 37/2008, Lifetime Coverage Against Manufacturing Defects
01 SV-IST Detailed Installation Instructions; The Following Must Be Observed: Connections, Polarity, Supply Voltage, Load
CLICK HERE TO DOWNLOAD THE MANUAL OR DIY GUIDE:
MANUFACTURER'S MANUAL
24-month warranty
