Description
Standalone access control
Mod. SF-AC101-2
SKU: SF-AC101-2
• Standalone access control
• Access via EM card and PIN
• 2 relay outputs, button, sensor and buzzer
• Wiegand 26
• Time control | Anti-passback
• Suitable for outdoor use IP68
DESCRIPTION:
• Safire
• Standalone access control
• Access via EM card, password and/or combinations
• Metal keypad and housing
• LED indicator
• Wiegand 26
• Integrated controller (button, sensor, buzzer and 2 relays)
• Opening and closing time control
• Anti-passback and airlock
• Suitable for outdoor use IP68
SPECIFICATIONS:
Brand
Safire
Model
SF-AC101-2
Capacity
Up to 2,000 cards/passwords
Identification modes
Card, PIN and combinations
Proximity card
RFID EM 125 kHz
Inputs
Door sensor
Outputs
2 NO/NC relays, button, alarm, buzzer and DC 12 V
Communication
Wiegand 26
Special functions
Anti-passback
Lock
Operation as a standalone terminal or reader
Monostable or bistable relay operation
Power supply
DC 12 V
Standby consumption
? 30 mA
Protection rating
Outdoor IP68
Operating temperature
-40° C ~ +60° C
Dimensions
78 (H) x 118 (W) x 25 (D) mm
Weight
700 g
CONTENTS:
Safire standalone access control keypad
• Installation materials
• User instructions
CLICK THE LINKS FOR THE MANUFACTURER'S DOCUMENTATION:
PDF datasheet
SF-AC101-2 User Manual
24-month warranty
