Safire Smart SF-IPT511ZA-6E1-DL E1 IP Bullet Camera

E1 IP bullet camera

Mod. SF-IPT511ZA-6E1-DL

SKU: SF-IPT511ZA-6E1-DL

• Safire Smart

• E1 range IP turret camera with Artificial Intelligence

• 6 Megapixel resolution (3200x1800) | Audio IN

• 2.8~12 mm motorized lens | IR and white light, 50 m

• AI: Person and vehicle classification

• IP67 waterproof | PoE (IEEE802.3af)


DESCRIPTION:

• Safire Smart

• E1 range with Artificial Intelligence

• IP turret camera

• 1/2.5" Progressive Scan CMOS

• 6 Megapixel (3200x1800)

• 2.8~12 mm motorized varifocal lens

• 0 Lux

• Dual IR and white light, 50 m range

• H.265+ / H.265 / H.264+ / H.264 compression

• WDR

• 3DNR

• Audio input

• Built-in microphone

• MicroSD card

• Artificial Intelligence: Person and vehicle classification

• WEB, CMS, smartphone and NVR interface

• ONVIF compatible

• PoE (IEEE802.3af)

• IP67 waterproof


SPECIFICATIONS:

Brand
Safire Smart

Range
E1

Optical sensor
1/2.5" Progressive Scan CMOS

Maximum resolution
6 Megapixel (3200x1800)

Minimum illumination
Color: 0.008 Lux @(F1.6, AGC ON), 0 Lux with IR

IR and white light range
IR: 40 m
White light: 50 m

Day/night
Removable mechanical ICR filter

Electronic Shutter
1/2~1/100,000 s

Main Stream Frame Rate
20 FPS (6Mpx)
30 FPS (4Mpx, 1080P)

Sub Stream Frame Rate
25 FPS (720P, D1, CIF)

Third Stream Frame Rate
25 FPS (D1, 480x240, CIF)

Compression
H.265+ / H.265 / H.264+ / H.264 / MJPEG

Bitrate
64 Kbps ~ 8 Mbps

Lens
2.8 ~ 12mm

Field of view (FOV)
H: 108-36°, V: 57-20°, D: 129-42°

DORI
66-204 m (D), 27-82 m (O), 13-41 m (R), 7-20 m (I)

Image enhancements
WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror function, Privacy Mask, ROI

Motion detection
Yes

Smart functions
Artificial intelligence based on person and vehicle classification for: area intrusion, line crossing, area entry, area exit
Other smart events: abandoned object, removed object, video exceptions (scene change, video loss, ...)

Audio
1 input / Built-in microphone

Audio compression
G711A / U

Network interface
Ethernet 10 / 100M BaseT

Internal memory
MicroSD card up to 256GB

Remote access
Web browser, Safire Smart smartphone app, Safire Smart VMS PC software

Interoperability
ONVIF

Power supply
DC 12 V / 9.5 W max. / PoE IEEE802.3af

Protection rating
Waterproof IP67

Material
Metal and plastic

Operating temperature
-30° C ~ +60° C

Dimensions
Ø111.6 x 99.6 mm

Weight
660 g


CONTENTS:

Safire Smart E1 IP Bullet Camera

• Installation materials

• Quick installation guide

CLICK THE LINKS FOR THE MANUFACTURER'S DOCUMENTATION:

PDF datasheet

User Manual 4&6MP E1 DL EN

Safire Smart VMS User Manual EN

24-month warranty
