Description
CHAIN ACTUATOR
Model MICRO EVO1 - 24V
SKU: 2713793
COLOR: Black RAL 9005
THRUST: 300 N
POWER: 24 W
PROTECTION RATING: IP32
MINIMUM SPEED: 13 mm/s
Linear electric actuator with a double-link articulated chain housed inside a metal casing.
Equipped with an overload protection system and automatic closing limit switch adjustment.
Features 4 electronically selectable stroke lengths.
Equipped with a synchronization system that coordinates the chain movement of up to 4 actuators without the need for an external control unit.
Complete with accessories for installation on outward-opening or tilt windows.
Stroke can be adjusted using the selector
Soft-stop closing to protect the window frame
Reduced height: 35 mm
FORCE: Max. thrust 300N
VOLTAGE: 24V
POWER: 24W
STROKE: 100 - 200 - 300 - 400
OPENING/CLOSING LIMIT SWITCH: Electronic
PROTECTION RATING: IP32
MINIMUM SPEED: 13 min/s
OPERATING TEMPERATURE: -10/+40° C
CERTIFICATIONS: CE - VDE
24-month warranty
